适用范围
1、1区、2区危险场所。
2、ⅡA、ⅡB、ⅡC类爆炸性气体环境。

Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in ⅡA、ⅡB、ⅡC group explosive atmosphere.

产品特点
1、外壳采用高强度难燃工程塑料压制而成，外形美观且有抗静电耐冲击及热稳定性好又耐腐蚀等优良性能。
2、具有联锁结构，只有插座内的开关分断后方能拔出插头。
3、插座上设有挂锁，在不使用时，可通过挂锁锁定，可使插座罩盖无法打开，便于现场监控。
4、钢管或电缆布线均可。
＊注：1、连接器作为电缆远距离连接之用。 2、连接器电流仅限于16A。
5、符合GB3836-2000，IEC60079标准要求。

Features
1、 The shell is made of high rigid, flame-proof engineering plastic with aesthetic outline, functions of electrostatic-resistant, impulsion-withstanding,
thermal stability and corrosion-proofing.
2、With interlocks, only if the switch inside socket is off, the plug can be brought out.
3、 Provision is made to offer padlock on socket. If out of operation, the socket cover can’t be opened by pad lock, so that local inspection and
witnss are easy.
4、Suitable for steel pipe and cable wiring.
*Note：1、Link used for connecting distance-cable. 2、Link’s current is only limited to 16A.
5、Suitable for GB3836-2000, IEC60079 standard request.
