BAT52系列防爆投光灯(IIB、IIC)


适用范围
1、1区、2区危险场所。
2、ⅡA、ⅡB类爆炸性气体环境。
3、可配装汞灯、高压钠灯、金卤灯。
*要求ⅡC类时请注明。


Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in ⅡA、ⅡB group explosive atmosphere.
3、Suitable for mercury vapor lamp, high-pressure sodium vapor lamp, metal halide lamp.
*Please note if need Ⅱ C group.

产品特点

1、铸铝合金外壳,压铸成形,表面喷塑。
2、灯体可在水平安装或壁式安装,仰角在45°~90°
内可调。
3、采用侧面开盖,便于更换灯泡。
4、采用桔纹漫反射板,使光线柔和且照射角大。
5、电缆布线。
6、符合GB3836-2000,IEC60079标准要求。

Features
1、Diecasted Al-alloy shell with plastic-sprayed surface.
2、Horizontal mounting or wall installing is available, elevation angle is adjustable
from 45°to 90°.
3、The side is opened, which is easy for installing and maintaining lamp.
4、Adopting reflection plate like orange surface so as to make light soft and
have large range of illumination.
5、Suitable for cable wiring.
6、Suitable for GB3836-2000, IEC60079 standard request.



主要技术参数 Main technical parameters
防爆标志
防护等级
电缆外径
进线口螺纹
灯座代号
Exde II BT3
Exde II CT3
IP55
10-14
3/4
E40


配用光源 Supplied with lamps
光源类型
目镇汞灯
高压汞灯
高压钠灯
金卤灯
额定电压(V)
220
额定功率(W)
250
175
150
175
250
250
250
450
400
400
400


壳体类型
功率(W)
质量(Kg)
I
150 175
7.5
II
250 100 150
9.3
