BAT51系列防爆投光灯(IIB、IIC)


适用范围
1、1区、2区危险场所。
2、ⅡA、ⅡB、ⅡC类爆炸性气体环境。
3、可配装汞灯、高压钠灯、金卤灯。
*要求ⅡC类时请注明。


Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in ⅡA、ⅡB、ⅡC group explosive atmosphere.
3、Suitable for mercury vapor lamp, high-pressure sodium vapor
lamp, metal halide lamp.
*Please note if need Ⅱ C group.

产品特点

1、铸铝合金外壳,压铸成形,表面喷塑。
2、灯体可在水平旋转360°,仰角在+90°
至-60°内可调。
3、反射罩采用抛物面形状,反射率高,针对
250W功率设有调焦机构,可实现远近调
节,远光时,射程能达100m。
4、有较强的防水性能,可使用于船舶或石油平
台等有较高防护要求的场所供照明之用。
5、电缆布线。
6、符合GB3836-2000,IEC60079标准要求。

Features
1、Diecasted aluminium alloy shell with plastic-sprayed surface.
2、The lamp body can be rotated 360° levelly and adjusted from +90°to
-60°elevately.
3、The reflector uses paroboloid shape, high reflectivity, aim at 250W power, it
has adjusting focus organization can realize hear and for adjustment, it can
reach 100m when it is far hight.
4、 With high performance of water-proofing and applicable to use in the place to illuminate that have higher protection demand, such as ship, petroleum platform, etc.
5、Suitable for cable wiring.
6、Suitable for GB3836-2000, IEC60079 standard request.



主要技术参数 Main technical parameters
防爆标志
防护等级
电缆外径
进线口螺纹
灯座代号
Exde II BT3
Exde II CT3
IP55
10-14
3/4
E40


配用光源 Supplied with lamps
光源类型
目镇汞灯
高压汞灯
高压钠灯
金卤灯
额定电压(V)
220
额定功率(W)
250
175
150
175
250
250
250
450
400
400
400
1000
